Will a B&CTWB100 work in a Cubo 18?
- Tralien
-
Topic Author
- Offline
- New Member
-
Less
More
3 years 1 month ago - 3 years 1 month ago #24878
by Tralien
Will a B&CTWB100 work in a Cubo 18? was created by Tralien
Hey all!
I have a B&C TWB100, Is it a good match up for this cabinet? or is there a better fit for enclosure design? This is my first build so just hoping to start off with a win!
Thanks in advance Nominal power handling1500 W Continuous power handling 3000 W Recommended enclosure 200.0 dm3 (7.06 ft3) Recommended tuning32 Hz Fs33 Hz Re3.2 Ω Qes 0.34 Qms 6.23Q ts 0.32 Vas181.5 dm3 (6.41 ft3)Sd1210.0 cm2 (187.6 in2)η₀1.8 %Xmax12.0 mmXvar14.0 mmMms268 gBl22.8 TxmLe1.64 mHEBP97 Hz
I have a B&C TWB100, Is it a good match up for this cabinet? or is there a better fit for enclosure design? This is my first build so just hoping to start off with a win!
Thanks in advance Nominal power handling1500 W Continuous power handling 3000 W Recommended enclosure 200.0 dm3 (7.06 ft3) Recommended tuning32 Hz Fs33 Hz Re3.2 Ω Qes 0.34 Qms 6.23Q ts 0.32 Vas181.5 dm3 (6.41 ft3)Sd1210.0 cm2 (187.6 in2)η₀1.8 %Xmax12.0 mmXvar14.0 mmMms268 gBl22.8 TxmLe1.64 mHEBP97 Hz
Last edit: 3 years 1 month ago by Tralien. Reason: Spacing is all wack making it hard to read
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
3 years 1 month ago #24879
by Cubo15
Replied by Cubo15 on topic Will a B&CTWB100 work in a Cubo 18?
Hi,
The 18TBW100 can be used in both Cubo 18 Extended (40 Hz, loudest) and Cubo Sub (30 Hz, largest). Do you have the 4 Ohm or the 8 Ohm version?
Cubo
The 18TBW100 can be used in both Cubo 18 Extended (40 Hz, loudest) and Cubo Sub (30 Hz, largest). Do you have the 4 Ohm or the 8 Ohm version?
Cubo
Please Log in or Create an account to join the conversation.
- Tralien
-
Topic Author
- Offline
- New Member
-
Less
More
- Posts: 3
- Thank you received: 0
3 years 1 month ago #24880
by Tralien
Replied by Tralien on topic Will a B&CTWB100 work in a Cubo 18?
Hey thanks for getting back to me.
I've got the four ohm version.
Is there more consideration with choosing either a 4 or 8 ohm load?
I feel like the Sub version maybe the way to go as low is my preference.
I've got the four ohm version.
Is there more consideration with choosing either a 4 or 8 ohm load?
I feel like the Sub version maybe the way to go as low is my preference.
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
3 years 4 weeks ago #24881
by Cubo15
Replied by Cubo15 on topic Will a B&CTWB100 work in a Cubo 18?
Apart from the different load resulting in different power options from amplifiers, the 8 and 4 Ohm version of a single driver (like the 18TBW100) can actually be quite different, the motor structure is the same but the voice coil is completely different. For some B&C models the differences between 4 and 8 Ohm versions are small but in this case the difference is significant, to the point that I prefer the 4 over the 8 Ohm version. The 4 Ohm version has higher EBP, lower Qts and Le, which are generally desired traits and it´s something I would look for when choosing Cubo 18 Extended.
The extended Xmax makes it a typical sub driver, I think Cubo Sub is the best choice here to get the maximum from the 18TBW100 if your choice of music requires it.
The extended Xmax makes it a typical sub driver, I think Cubo Sub is the best choice here to get the maximum from the 18TBW100 if your choice of music requires it.
Please Log in or Create an account to join the conversation.
- Tralien
-
Topic Author
- Offline
- New Member
-
Less
More
- Posts: 3
- Thank you received: 0
3 years 4 weeks ago #24883
by Tralien
Replied by Tralien on topic Will a B&CTWB100 work in a Cubo 18?
Thanks Cubo! Great information, Thank you!
The B&C drivers are relatively easy for me to get, but my knowledge in what to get is lacking. When I ordered that driver I was kind of rolling the dice to be honest.
I was planning on building a cubo kick 15 as well, but hadn't started looking at drivers for it as of yet. What do you think would be a good B&C pairing for the TWB100 18" driver cubo sub?
Just curious do you have any build pictures of the inside of a cubo sub?
Cheers
The B&C drivers are relatively easy for me to get, but my knowledge in what to get is lacking. When I ordered that driver I was kind of rolling the dice to be honest.
I was planning on building a cubo kick 15 as well, but hadn't started looking at drivers for it as of yet. What do you think would be a good B&C pairing for the TWB100 18" driver cubo sub?
Just curious do you have any build pictures of the inside of a cubo sub?
Cheers
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
3 years 4 weeks ago #24884
by Cubo15
Replied by Cubo15 on topic Will a B&CTWB100 work in a Cubo 18?
Most diy build pics of Cubo Sub show the outside of the cabinet, is there anything specific you're looking for?
One Cubo Kick 15 with 500 W generally keeps up with up to 2 x Cubo Subs each getting 1000 W. From B&C the 15NW76, 15NDL76 and 15NDL88 are a good match.
One Cubo Kick 15 with 500 W generally keeps up with up to 2 x Cubo Subs each getting 1000 W. From B&C the 15NW76, 15NDL76 and 15NDL88 are a good match.
