Cubo Kick 15

More
7 years 1 month ago #24115 by tc87
Replied by tc87 on topic Cubo Kick 15
Could someone email me the plans for cubo kick 15 please, I can't seem to find them :)
Tomas.Clausen87@gmail.com

Please Log in or Create an account to join the conversation.

  • Cubo15
  • Topic Author
  • Offline
  • Platinum Member
  • Platinum Member
More
7 years 4 weeks ago #24116 by Cubo15
Replied by Cubo15 on topic Cubo Kick 15
The plans for Cubo Kick are 'hidden' on the first page of this topic ;)

Best regards Cubo
The following user(s) said Thank You: tc87

Please Log in or Create an account to join the conversation.

More
7 years 1 week ago - 7 years 1 week ago #24135 by Maikolmks
Replied by Maikolmks on topic Cubo Kick 15
Hello Mr. CUBO,
I would like to build Cubo Kick in version 215 with a maximum length of 118 cm. (45 cm wide for driver 12") What do you think?
I have four B&C 12nw76, can they work in Cubo kick?
Attachments:
Last edit: 7 years 1 week ago by Maikolmks.

Please Log in or Create an account to join the conversation.

More
7 years 1 week ago #24136 by ricosound
Replied by ricosound on topic Cubo Kick 15
I use B&C 12nw76 on cubo kicks and they sound great. I have them on 2 single Cubo Kick 12" and on top of 4 Cubo12" as bass part, sometimes in a combination with 2 Cubo15 + 2 Cubo12
The following user(s) said Thank You: Maikolmks

Please Log in or Create an account to join the conversation.

More
7 years 1 week ago #24138 by Maikolmks
Replied by Maikolmks on topic Cubo Kick 15
I have long been using the LEM K180 (similar to ELECTROVOICE SENTRY IV) cabins with 12nw76, the sound is very strong. But i would like to build a kick cube to compare them
Attachments:

Please Log in or Create an account to join the conversation.

  • Cubo15
  • Topic Author
  • Offline
  • Platinum Member
  • Platinum Member
More
7 years 1 week ago #24141 by Cubo15
Replied by Cubo15 on topic Cubo Kick 15
The 12NW76 will work in Cubo Kick at 45 cm wide. It won't drop as low as the LEM but really focus at 90 - 210 Hz. If you put them with the mouths together, take away from the middle of the cabinet to make them 118 cm.

Regards Cubo
The following user(s) said Thank You: Maikolmks

Please Log in or Create an account to join the conversation.

More
6 years 11 months ago #24146 by tonskulus
Replied by tonskulus on topic Cubo Kick 15
I have four RCF L12L750, should be good for midbass-midrange. What do you think, any good for cubo kick 12?

fs 62Hz
Qts 0.27
Qms 4.1
Qes 0.29
BL 18.8
Vas 52litres
xmax 3.5mm
4 inch voice coil
EBP 213

Please Log in or Create an account to join the conversation.

  • Cubo15
  • Topic Author
  • Offline
  • Platinum Member
  • Platinum Member
More
6 years 11 months ago #24153 by Cubo15
Replied by Cubo15 on topic Cubo Kick 15
They look like capable drivers for anything above 100 Hz (be it Cubo Kick 12 or a 12" mid-top). In Cubo Kick 12, I would expect them to do 100 - 250 Hz well (either as singles or multiples). Wadding on all walls inside the chamber, without restricting air flow to the driver and port would be preferential.

Best regards Cubo

Please Log in or Create an account to join the conversation.

More
6 years 11 months ago #24166 by Colboy
Replied by Colboy on topic Cubo Kick 15
Im wondering how these would be in Cubo kick.
Beyma 15p80nd
15 Fs 33 Hz
Re 5.1 ohm
Qms 7.7
Qes 0.182
Qts 0.178
Vas 250 l
Cms 229 micro m / N
Rms 2.73 kg/s
Efficiency % 4.77
Sd 0.088 sqm
Xmax 7.5 mm
Vd 660 cu cm
Le @1 kHz 0.8 mH

Please Log in or Create an account to join the conversation.

  • Cubo15
  • Topic Author
  • Offline
  • Platinum Member
  • Platinum Member
More
6 years 11 months ago #24169 by Cubo15
Replied by Cubo15 on topic Cubo Kick 15
The 15P80Nd will perform equally well as the original driver (15ND930), except that it has a 4" voice coil, making it a good choice for a high power kick bin.

Best regards Cubo

Please Log in or Create an account to join the conversation.
