Cubo 18

@t.geessounds: The're looking lush!

@kotovics: HPF 35 Hz, 24 dB/ octave (BW). LPF 80 - 100 Hz, 24 dB/ octave (LR). Delay on the tops is usually not necessary., nor is the use of EQ (too taste however).

Best regards

Cubo

Are there any plans to make the Cubo18 as one double loaded bass bin?

If anyone has had a go at this is are there any plans available?

Yeah, see below.







Best regards

Cubo

:

These are at a total of 100 cm high:

0772765437

Hi Cubo thought you might like this I'm just starting work on two of them( I have a pair of single Cubos already).
If its ok with you I will post the twin drawings on here for those who are asking for them.

Hey.
I am looking into building A smal/Compact Mono System Of Cubos.
If I build One of This Double Cubo 18sub What other cubos would stack well for Low and mid kick ?
Regards joko

@andy471man: Sounds like a plan! With what software did you create those drawnings?

@Amonyma: A Cubo 218 is a good match for a Cubo Kick 15 ( www.freespeakerplans.com/kunena/7-genera...m/20750-cubo-kick-15 ). What other Cubo's stack well depends on what measurements you end up with. Generally speaking the same drivers in the same cabinets are the best match, but most Cubo 15 and Cubo 18 variations will work without special processing.

Best regards

Cubo

Good afternoon!
William'm from Brazil, I would get the project "Cube 18 Extended", have 3 drivers to use in this project, wanted to know what the most appropriate.

1 - SELENIUM 18SW3P ( www.lautsprechershop.de/pdf/selenium/selenium_18sw3p.pdf )
2 - OVERSOUND SUB800 ( www.oversound.com.br/produtos/sub-800 )
3 - OVERSOUND 18.2-600 ( www.oversound.com.br/produtos/18-2-600 )

Note: These three models have equivalent 15 "

Could send me the project in pdf? Actually still could not understand the difference between the Cube 18 Standard and Extended.

I want only the "CUB 18 Extended Project".

Note: Sorry errors in writing, I am using a translator.

Regards,
William

The Sub800 seems like a very good option, followed by both the Selenium and the Oversound 18.2-600, which seem to be quite alike in overall performance but not as good as the Sub800 (all best for Cubo 18 Extended).

1 - OVERSOUND SUB800 ( www.oversound.com.br/produtos/sub-800 )
2 - SELENIUM 18SW3P ( www.lautsprechershop.de/pdf/selenium/selenium_18sw3p.pdf ) and OVERSOUND 18.2-600 ( www.oversound.com.br/produtos/18-2-600 )

If you tell me which 15" drivers are the supposed equivalents of these drivers I can grade them.

The project doesn't exist in pdf by my knowledge. If you decide too create them yourself, I would happily distribute them, if asked for.

The difference between Cubo Standard and Extended is a single panel of 18 x 58,4 cm, which "Ëxtends" the horn path. Put the construction drawing of Cubo Standard and Extended next to each other if you still don't see it.

Best regards

Cubo
