- Posts: 916
- Thank you received: 131
Cubo 18
- Cubo15
- Offline
- Platinum Member
Cubo 18 Extended boasts a similar sensitivity around 80 - 100 Hz as the Sub 1.18 but should be much flatter below that, which you will notice with the right kind of music, if not most mainstream sound.
Best regards
Cubo
Please Log in or Create an account to join the conversation.
- t.geessounds
- Offline
- Elite Member
- Posts: 172
- Thank you received: 4
Cubo15 wrote: The L18P300 works in both but if you haven't build anything yet, I would recommend building Cubo 18 Extended.
Recently someone in The Netherlands made 14 (custom designed) Cubo 18 Extended with the L18P300: s31.postimg.org/ek4uysru3/Foto_26_06_16_13_08_45.jpg Thread (with many build pics): www.new-line.nl/forum/read/?m=710476
Best regards
Cubo
are these box taller than the normal cubo 18??
Please Log in or Create an account to join the conversation.
- Knobs100
- Offline
- New Member
- Posts: 3
- Thank you received: 0
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
- Posts: 916
- Thank you received: 131
@Knobs100: According to the pdf, the EVX-180B low-frequency transducer is designed for professional sound reinforcement or studio monitoring applications. That last bit "studio monitoring" often hints at a lack in power handling for PA and in this case it doesn't seem to be an exception. The EVX-180B are very nice drivers overall and are likely to emphasize the lower kick but how in the heck they're supposed to be 600 Watts I can't seem to grasp.
They will work best in Cubo 18 Extended, with a decent high pass at 40 -ish Hz. My initial guess would be to hook them up with 500 - 750 W amplifier, kept away from clip.
Best regards
Cubo
Please Log in or Create an account to join the conversation.
- songatron
- Offline
- New Member
- Posts: 4
- Thank you received: 0
Any help would be much appreciated.
Thanks!
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
- Posts: 916
- Thank you received: 131
Theoretically you could iron the differences out using EQ, if you're using the same driver in each, I doubt that it will be necessary though.
Best regards
Cubo
Please Log in or Create an account to join the conversation.
- t.geessounds
- Offline
- Elite Member
- Posts: 172
- Thank you received: 4
am look to build 4 double to replace 4 double 18 bassreflex...(just not happy with the output) think ill get more from a double cubo but have a little problem my my low mids are 71cm deep an 61cm width .. so can this plan be mod to be 122cm x 71cm x 61cm
thanks
Cubo15 wrote: Yeah, see below.
Best regards
Cubo
:
Please Log in or Create an account to join the conversation.
- t.geessounds
- Offline
- Elite Member
- Posts: 172
- Thank you received: 4
Please Log in or Create an account to join the conversation.
- redtag
- Offline
- New Member
- Posts: 18
- Thank you received: 1
I wanna build 2 Cubo18 Extended with 18LW1400 and wonder how much amp power I need. Can someone recommend any amp? I have one QSC 1450 but I think I need more. And what Top are recommended for Cubos? And what drivers in them.. cheers!
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
- Posts: 916
- Thank you received: 131
@redtag: You could use one 1450 bridged @8 Ohm but the power of a RMX5050 is more like it. The 1450 could then be used on some tops. A pair of decent 12"/1" tops will keep up with a pair of Cubo 18 Extended.
Best regards
Cubo
Please Log in or Create an account to join the conversation.
