- Posts: 3
- Thank you received: 0
Cubo Kick
- resko1
-
- Offline
- New Member
-
Less
More
3 years 1 month ago #24875
by resko1
Replied by resko1 on topic Cubo Kick
Would the 15nw76 be a suitable driver for the kick 15?
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
3 years 1 month ago #24876
by Cubo15
Replied by Cubo15 on topic Cubo Kick
Yes, the 15nw76 has written kick all over it.
Please Log in or Create an account to join the conversation.
- Lionheart
-
- Offline
- New Member
-
Less
More
- Posts: 1
- Thank you received: 0
2 years 11 months ago #24908
by Lionheart
Replied by Lionheart on topic Cubo Kick
Tell me can I use Celestion ftr4080fd in a cubo kick ?
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
2 years 11 months ago #24909
by Cubo15
Replied by Cubo15 on topic Cubo Kick
The 15" or the 18"?
Please Log in or Create an account to join the conversation.
- freqmason
-
- Offline
- New Member
-
Less
More
- Posts: 1
- Thank you received: 0
2 years 10 months ago #24919
by freqmason
Replied by freqmason on topic Cubo Kick
Hello Cubo! I'm using 4 of your 15" sub design and looking to build a pair of the 15" kick bins to go with them. is it possible to obtain the plans in imperial measurements somewhere?
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
2 years 10 months ago #24920
by Cubo15
Replied by Cubo15 on topic Cubo Kick
I think the easiest way is to find a Sketchup model, or put in the parameters in Sketchup (2D) in Metric (centimeters), then change to Imperial (Window - Model Info - Units - Decimal/ Fractional).
Cubo
Cubo
Please Log in or Create an account to join the conversation.
- Stefist
-
- Offline
- New Member
-
Less
More
- Posts: 2
- Thank you received: 0
2 years 9 months ago #24929
by Stefist
Replied by Stefist on topic Cubo Kick
Hello !
Any Idea for a 18" speaker that could fit in the cubo kick 18 ??
Thanks
Any Idea for a 18" speaker that could fit in the cubo kick 18 ??
Thanks
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
2 years 9 months ago #24931
by Cubo15
Replied by Cubo15 on topic Cubo Kick
Personally I like drivers like the 18Sound 18W2000, typically low Qes (0.2 - 0.3), low to medium medium Vas (say below 250 liter), medium Xmax (you don't need a lot) and preferably a low Le. These kind of drivers tend to have an n0 (Eta zero) around 3% or higher and an EBP above 100.
faitalpro.com/en/products/LF_Loudspeaker...dex.php?id=151070160
faitalpro.com/en/products/LF_Loudspeaker...dex.php?id=201070115
Faital Pro exaggerates the Xmax figures a bit, otherwise I would say Xmax below 9 mm, higher is usually a sign that it's more a sub driver.
faitalpro.com/en/products/LF_Loudspeaker...dex.php?id=151070160
faitalpro.com/en/products/LF_Loudspeaker...dex.php?id=201070115
Faital Pro exaggerates the Xmax figures a bit, otherwise I would say Xmax below 9 mm, higher is usually a sign that it's more a sub driver.
Please Log in or Create an account to join the conversation.
- mikael.haggman
-
- Offline
- New Member
-
Less
More
- Posts: 2
- Thank you received: 0
2 years 8 months ago #24940
by mikael.haggman
Replied by mikael.haggman on topic Cubo Kick
Do you think this cabinet will work with a Ciare 15 ndh driver. See specs below:
Qms 11.19
Qes 0.26
Qts 0.25
Fs 27.90 Hz
Re 6.04 Ohm
Mms 143.00 g
Cms 0.23 mm/N
Bl 24.19 T*m
Sd 830.00 cm2
Vas 219.93 liter
u0 1.78 %
XMax 11.5 mm
Le 1.07 mH
Rms 2.24 Kg/s
Efficiency Bandwidth 107.83
Qms 11.19
Qes 0.26
Qts 0.25
Fs 27.90 Hz
Re 6.04 Ohm
Mms 143.00 g
Cms 0.23 mm/N
Bl 24.19 T*m
Sd 830.00 cm2
Vas 219.93 liter
u0 1.78 %
XMax 11.5 mm
Le 1.07 mH
Rms 2.24 Kg/s
Efficiency Bandwidth 107.83
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
2 years 8 months ago #24941
by Cubo15
Replied by Cubo15 on topic Cubo Kick
The Ciare 15 ndh driver will work but it's more of a bass/ sub driver, due to it's motor topology (30 mm winding depth) it's designed to have optimal cooling at large excursions. Typical excursion in Cubo Kick is 3 - 5 mm. At low to medium power levels it will be OK (500 - 700 W), well away from clipping, at high power levels (> 700 W) it might burn the ends of the voice coil, as they will never get close enough to the magnetic gap to properly cool (due to a lack of excursion). It's a perfect high power driver for Cubo 15 Extended though.
Please Log in or Create an account to join the conversation.
