2 years 10 months ago #24952
by mikael.haggman
Replied by mikael.haggman on topic Cubo Kick
Thanks for your reply. But it seems I copied the wrong parameters (sorry for that). They were for the 15-4 S. The right theile below. That might work better with the lower Xmax? The plan is to use this Kick as a low mid driver in combination with a Cubo 18 and a mid/HF cabinett on each side ran on Lab 4000, Lab 2000c and Lab 1300c.
Qms 11,81
Qes 0,31
Qts 0,31
Fs 48,60 Hz
Re 6,06 Ohm
Mms 107,00 g
Cms 0,19 mm/N
Bl 25,09 T*m
Sd 830,00 cm2
Vas 96,87 liter
u0 3,41 %
XMax 8 mm
Le 0,71 mH
Rms 2,77 Kg/s
Efficiency Bandwidth 154,52
Qms 11,81
Qes 0,31
Qts 0,31
Fs 48,60 Hz
Re 6,06 Ohm
Mms 107,00 g
Cms 0,19 mm/N
Bl 25,09 T*m
Sd 830,00 cm2
Vas 96,87 liter
u0 3,41 %
XMax 8 mm
Le 0,71 mH
Rms 2,77 Kg/s
Efficiency Bandwidth 154,52
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
Less
More
- Posts: 919
- Thank you received: 132
2 years 10 months ago #24960
by Cubo15
Replied by Cubo15 on topic Cubo Kick
OK, that's a better choice. Let's not pin it down on one parameter though, like Xmax, although an u0 over 3 % is a good indicator for a 12" or 15" kick driver.
Best regards Cubo
Best regards Cubo
Please Log in or Create an account to join the conversation.
- smegdubz
- Offline
- New Member
Less
More
- Posts: 1
- Thank you received: 0
2 years 5 months ago #24993
by smegdubz
Replied by smegdubz on topic Cubo Kick
Hello there, would Fane Sovereign 12-300 work in Cubo Kick 12? Or other from Fane product range. Looking to use 12-300 in cubo 12's and want to build kicks as well, sticking with the same manufacturer. Not sure what parameters are crucial in kick design. thanks!
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
Less
More
- Posts: 919
- Thank you received: 132
2 years 5 months ago - 2 years 5 months ago #24994
by Cubo15
Replied by Cubo15 on topic Cubo Kick
I would go with the 12-300 for both Cubo 12 and Cubo Kick 12 (higher efficiency/ lower Qts works well in both designs).
Cubo
Cubo
Last edit: 2 years 5 months ago by Cubo15.
Please Log in or Create an account to join the conversation.
- modalen
- Offline
- New Member
Less
More
- Posts: 1
- Thank you received: 0
2 years 5 months ago #24999
by modalen
Replied by modalen on topic Cubo Kick
I have a few RCF MB15N351.
Would they be oki for Cubo kick?
Resonant frequency fS 42 Hz
Electrical Q QES 0.24
Mechanical Q QMS 4.00
Total Q factor QTS 0.22
Suspension equivalent air volume VAS 191 litres
DC resistance RE 5.6 Ω
Minimum impedance Zmin 6.0 Ω
Voice coil inductance LE 1.65 mH
Force factor B·l 22.5 T·m
Suspension mechanical resistance RMS 5.3 N·s/m
Suspension mechanical compliance CMS 166 µm/N
Moving mass MMD 61.4 g
Moving mass (including airload) MMS 80 g
Surface of the diaphragm SD 900 cm²
Effective diaphragm diameter Ø 33 cm
Maximum linear excursion Xmax ± 6 mm
Excursion limit Xlim ± 19.5 mm
Displacement volume at Xmax VD 540 cm³
Efficiency η₀ 5.68 %
Efficiency bandwidth product EBP 175
Would they be oki for Cubo kick?
Resonant frequency fS 42 Hz
Electrical Q QES 0.24
Mechanical Q QMS 4.00
Total Q factor QTS 0.22
Suspension equivalent air volume VAS 191 litres
DC resistance RE 5.6 Ω
Minimum impedance Zmin 6.0 Ω
Voice coil inductance LE 1.65 mH
Force factor B·l 22.5 T·m
Suspension mechanical resistance RMS 5.3 N·s/m
Suspension mechanical compliance CMS 166 µm/N
Moving mass MMD 61.4 g
Moving mass (including airload) MMS 80 g
Surface of the diaphragm SD 900 cm²
Effective diaphragm diameter Ø 33 cm
Maximum linear excursion Xmax ± 6 mm
Excursion limit Xlim ± 19.5 mm
Displacement volume at Xmax VD 540 cm³
Efficiency η₀ 5.68 %
Efficiency bandwidth product EBP 175
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
Less
More
- Posts: 919
- Thank you received: 132
2 years 5 months ago #25002
by Cubo15
Replied by Cubo15 on topic Cubo Kick
Those are oki for sure,
The RCF MB15N351 has been optimized for mid-kick, the only draw back might be the light-ish cone, I would put a lot of dampening material on the walls of the rear chamber (just in case).
Cubo
The RCF MB15N351 has been optimized for mid-kick, the only draw back might be the light-ish cone, I would put a lot of dampening material on the walls of the rear chamber (just in case).
Cubo
Please Log in or Create an account to join the conversation.
- jsoto
- Offline
- New Member
Less
More
- Posts: 1
- Thank you received: 0
2 years 1 week ago #25018
by jsoto
Replied by jsoto on topic Cubo Kick
Hi Cubo! Wonderful design! How would the Celestion FTR15-4080FD work in the Cubo Kick?
Resonant frequency fS 35.4 Hz
Electrical Q QES 0.30
Mechanical Q QMS 3.91
Total Q factor QTS 0.28
Suspension equivalent air volume VAS 164.3 litres
DC resistance RE 5.6 Ω
Voice coil inductance LE 1.38 mH
Force factor B·l 23.05 T·m
Suspension mechanical resistance RMS 7.24 N·s/m
Suspension mechanical compliance CMS 160 µm/N
Moving mass MMD 112.24 g
Moving mass (including airload) MMS 127.19 g
Surface of the diaphragm SD 850.9 cm²
Effective diaphragm diameter Ø 33 cm
Maximum linear excursion Xmax ± 6 mm
Displacement volume at Xmax VD 510.5 cm³
Efficiency η₀ 2.37 %
Efficiency bandwidth product EBP 118
Resonant frequency fS 35.4 Hz
Electrical Q QES 0.30
Mechanical Q QMS 3.91
Total Q factor QTS 0.28
Suspension equivalent air volume VAS 164.3 litres
DC resistance RE 5.6 Ω
Voice coil inductance LE 1.38 mH
Force factor B·l 23.05 T·m
Suspension mechanical resistance RMS 7.24 N·s/m
Suspension mechanical compliance CMS 160 µm/N
Moving mass MMD 112.24 g
Moving mass (including airload) MMS 127.19 g
Surface of the diaphragm SD 850.9 cm²
Effective diaphragm diameter Ø 33 cm
Maximum linear excursion Xmax ± 6 mm
Displacement volume at Xmax VD 510.5 cm³
Efficiency η₀ 2.37 %
Efficiency bandwidth product EBP 118
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
Less
More
- Posts: 919
- Thank you received: 132
2 years 4 days ago #25021
by Cubo15
Replied by Cubo15 on topic Cubo Kick
The Celestion FTR15-4080FD is an allround driver, whether it's bass, mid or kick, it should feel right at home.
Please Log in or Create an account to join the conversation.
- lechris
- Offline
- New Member
Less
More
- Posts: 1
- Thank you received: 0
1 year 11 months ago #25023
by lechris
Replied by lechris on topic Cubo Kick
In 2020 I've built two Cubo Kick 15 based on 18Sound 15ND930 for a venue in Leipzig.
Now that we have events again I can say that I am very happy with these speakers and I would say the build was a success.
During this build, I recreated the drawing by Cubo in Librecad to figure out some dimensions I could not discern from the drawing and to decide on details like where to put terminal plates and mounting holes for the speaker or the rear wall.
Maybe this can also be helpful for some other people who are building Cubo Kick 15, so I decided to share these drawings.
The proposed locations dimensions should provide clearance for Adam Hall 87160 Terminal plates and 18 Sound 15ND930. For other drivers/terminal plates, your mileage may vary.
Now that we have events again I can say that I am very happy with these speakers and I would say the build was a success.
During this build, I recreated the drawing by Cubo in Librecad to figure out some dimensions I could not discern from the drawing and to decide on details like where to put terminal plates and mounting holes for the speaker or the rear wall.
Maybe this can also be helpful for some other people who are building Cubo Kick 15, so I decided to share these drawings.
The proposed locations dimensions should provide clearance for Adam Hall 87160 Terminal plates and 18 Sound 15ND930. For other drivers/terminal plates, your mileage may vary.
Please Log in or Create an account to join the conversation.
- Cubo15
- Offline
- Platinum Member
Less
More
- Posts: 919
- Thank you received: 132
1 year 11 months ago #25026
by Cubo15
Replied by Cubo15 on topic Cubo Kick
Thanks man, appreciate it.
