- Posts: 916
- Thank you received: 131
Cubo 15
- Cubo15
-
- Offline
- Platinum Member
-
Fs^3 x Vas / Qes x 9.6E--8
Half space sensitivity: 112 + 10 x log (n0/100)
So for the L15P540
50^3 x 100 / 0.41 x 9.6E-8 = 2.93%
112 + 10 x log (0.0293) = 96.7 dB/W/m
As most 4" VC drivers have a lower Fs,you would have to raise Vas and lower Qes a bit to compensate.
Best regards Cubo
Please Log in or Create an account to join the conversation.
- tonskulus
-
- Offline
- New Member
-
- Posts: 11
- Thank you received: 2
Cubo15 wrote: n0 is the driver efficiency (in %), some manufacturers give it in the PDF. It's also used to calculate the drivers sensitivity (although most manufacturers use sensitivity figures from a rampant marketing department). n0 (a.k.a. Eta Zero a.k.a Reference Efficiency) is calculated from the Fs, Qes and Vas as follows:
Fs^3 x Vas / Qes x 9.6E--8
Half space sensitivity: 112 + 10 x log (n0/100)
So for the L15P540
50^3 x 100 / 0.41 x 9.6E-8 = 2.93%
112 + 10 x log (0.0293) = 96.7 dB/W/m
As most 4" VC drivers have a lower Fs,you would have to raise Vas and lower Qes a bit to compensate.
Best regards Cubo
Thanks! I'll keep my eyes on similar drivers having 4" coil etc..
L15P540 is still good driver anyway, nothing wrong with that.. tight and punchy. Sometimes these drivers are making loud bangs (input power around 1kW peak) while cone moving around 15-20mm only..sounds like coil hitting back plate. However, specs says Xdamage being as high as 36mm!
No matter if rising HP up to 45-50Hz, still bottoming or something similar if pushed up to 1kW.
Please Log in or Create an account to join the conversation.
- Slotcar55
-
- Offline
- New Member
-
- Posts: 1
- Thank you received: 0
Qms 2,59
Qes 0,28
Qts 0,25
Fs 31,20 Hz
Re 5,96 Ohm
Mms 160,97 g
Cms 0,16 mm / N
Bl 26,09 T * m
Sd 830,00 cm2
Vas 156,24 litri
u 1,66%
XMax 11,5 mm
Le 1,07 mH
Rms 12,18 Kg / s
Larghezza di banda di efficienza 112,92
could it be a good choice?I have a couple of them at home and I would like to use them to build a couple of compact divers for a small PA. what could be about the pressure in spl max achievable?
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
- Posts: 916
- Thank you received: 131
You can use the Ciare NDC 15-4S in Cubo 15 Extra Extended (send me an e-mail at questionsaboutcubo at gmail dot com) or in Cubo Sub. In Cubo 15 it will have about 100 dB/W/m sensitivity, so about 130 dB continuously (not factoring power compression). In Cubo Sub it's about 3 - 5 dB lower, so 125 - 127 dB continuously but what you miss in SPL you'll get back in air movement if playing 30 - 40 Hz.
Best regards Cubo.
Please Log in or Create an account to join the conversation.
- caczank
-
- Offline
- New Member
-
- Posts: 2
- Thank you received: 0
What I need: A pair of small bass cabinets to play live with my small band (4 components: drums, keyboards, acoustic guitar, vocals. The bass line is played from the keyboard). Other important point is there this bass cabinets need to be easy to be moved from one place to another. For me the cubo desing is the best compromise between space and SPL.
The way whic I will use 2 cubos is runing it by a DBX drive rack PA2, for use the crossovers, compression and limiter, and power it by an NUKE 3000 amp (~2000 W RMS @ 4 ohms bridged).
The drivers which are possible at Brazil are:
Snake Pro ESX155 - Cost 609 BRL
Cms - NA mm/N
FS 35 Hz
Qms 7,123
Qes -0.362
Qts - 0.345
Le - 0,92 mH
Vas - 193 L
Power (RMS) - 600 Watt
Re - - Ω
Coil - 100 mm
Impedance (Ohm) - 8 ohm
Mms - 107g
Sens. - 97dB
Xmax - 9,5mm
EBP 101
QtsxVas 66,6
Eff 2,6%
RCF 15P540 - Cost 839 BRL
Cms - NA mm/N
FS 50 Hz
Qms 9,7
Qes -0,41
Qts - 0,39
Le - 1,5 mH
Vas - 100 L
Power (RMS) - 500 Watt
Re 5,6 Ω
Coil - 76 mm
Impedance (Ohm) - 8 ohm
Mms - 106g
Sens. - 98 dB
Xmax - 7 mm
EBP 128
QtsxVas 39
Eff 2,94%
The tops which I use are 2 full range 200 W RMS, 12 pol woofer and driver, crossed, and use it in stereo mode. I will cross the cubos, to run in mono, at HP @ 40 Hz and LPF @ 100 ~110Hz. The system is for live sound in open and close spaces, but not at so high loud levels.
The questions:
1. What are the cost benifit choice between the 2 drivers?
2. What is the correct choice: cubo 15 standart or extended?
Thanks in advance for the support and attention. All information in this forum is very hellpfull. I'm read the full topic for cubo 12 and now i'm reading the topic for cubo 15 (at page 44).
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
- Posts: 916
- Thank you received: 131
I've updated the plans page, to include an easy calculation to what version suits what driver best:
Qts x Vas > 120, Cubo Standard
Qts x Vas = 100 - 120, Cubo Extended or Standard
Qts x Vas < 100, Cubo Extended
Qts x Vas < 50; Cubo 15 Extra Extended
Best regards Cubo
Please Log in or Create an account to join the conversation.
- redtag
-
- Offline
- New Member
-
- Posts: 18
- Thank you received: 1
![:p :p](/media/kunena/emoticons/16.png)
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
- Posts: 916
- Thank you received: 131
Best regards Cubo
Please Log in or Create an account to join the conversation.
- redtag
-
- Offline
- New Member
-
- Posts: 18
- Thank you received: 1
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
- Posts: 916
- Thank you received: 131
Best regards Cubo
